| Function | VE819R | VE819T |
| Video Input | ||
| Interfaces | N/A | 1 x HDMI Type A Male (Black) |
| Impedance | N/A | 100 ? |
| Max. Distance | N/A | N/A |
| Video Output | ||
| Interfaces | 1 x HDMI Type A Female (Black) | N/A |
| Impedance | 100 ? | N/A |
| Video | ||
| Max. Data Rate | 6.75 Gbps (2.25 Gbps Per Lane) | 6.75 Gbps (2.25 Gbps Per Lane) |
| Max. Pixel Clock | 225 MHz | 225 MHz |
| Compliance | HDMI (3D) HDCP Compatible | HDMI (3D) HDCP Compatible |
| Max. Resolutions / Distance | Up to 1080p/60Hz@10m (Line of Sight) * | Up to 1080p/60Hz@10m (Line of Sight) * |
| Audio | ||
| Input | N/A | 1 x HDMI Type A Male (Black) |
| Output | 1 x HDMI Type A Female (Black) | N/A |
| Control | ||
| IR | 1 x 2.5mm Mini Stereo Jack Female (Black) | N/A |
| Connectors | ||
| Power | 1 x Mini USB Jack | 1 x Mini USB Jack |
| Power Consumption | 5 VDC, 7.5W (Mini USB) | 5 VDC (Mini USB) |
| Environmental | ||
| Operating Temperature | 0 - 40°C | 0 - 40°C |
| Storage Temperature | -20 - 60°C | -20 - 60°C |
| Humidity | 0 - 80% RH, Non-Condensing | 0 - 80% RH, Non-Condensing |
| Physical Properties | ||
| Housing | Plastic | Plastic |
| Weight | 0.13 kg ( 0.29 lb ) | 0.03 kg ( 0.07 lb ) |
| Dimensions (L x W x H) | 9.50 x 9.50 x 3.33 cm (3.74 x 3.74 x 1.31 in.) | 3.00 x 7.03 x 1.75 cm (1.18 x 2.77 x 0.69 in.) |
| Carton Lot | 5 pcs | 5 pcs |
| Note | * Distance may vary depending on the actual environment; solid objects such as steel, concrete or brick may cause interference and shorten the transmission distances. | * Distance may vary depending on the actual environment; solid objects such as steel, concrete or brick may cause interference and shorten the transmission distances. |
| Note | For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format. | |
