| Source audio input channel | |||||
| Audio Output | Stereo (LPCM 2) | DTS 5.1 Dolby 5.1 | LPCM 5.1 | DTS 7.1 Dolby 7.1 | LPCM 7.1 |
| TosLink | Stereo | DTS 5.1 Dolby 5.1 | 2 channel (Front Right & FrontLeft) | Non support | 2 channel (Front Right & FrontLeft) |
| Coaxial | Stereo | DTS 5.1 Dolby 5.1 | 2 channel (Front Right & FrontLeft) | Non support | 2 channel (Front Right & FrontLeft) |
| Stereo | Stereo | Non support | 2 channel (Front Right & FrontLeft | Non support | 2 channel (Front Right & FrontLeft) |
| Connectors | Input | HDMI | 1 x HDMI Female (Black) |
| Output | HDMI | 1 x HDMI Female (Black) | |
| Audio | 1 x TOSLINK (Optical) | ||
| 1 x RCA (Coaxial) | |||
| 2 x RCA (Stereo) | |||
| Power | 1 x DC Jack | ||
| F/W Upgrade | 1 x 4-conductor 3.5 mm Jack | ||
| LEDs | Power | 1 (Green) | |
| Switches | Audio Channel | 1 x Dip Switch | |
| HDMI Audio On/Off | 1 x Dip Switch | ||
| F/W Upgrade | 1 x semi-recessed pushbutton | ||
| Video | Up to 1920 x 1080 | ||
| Power Consumption | DC5.3V, 0.8W | ||
| Environment | Operation Temp. | 0 - 50°C | |
| Storage Temp. | -20 - 60°C | ||
| Humidity | 0–80% RH, Non-condensing | ||
| Physical Properties |
Housing | Metal | |
| Weight | 0.46 kg | ||
| Dimensions (L x W x H) |
20.00 x 8.20 x 2.5 cm | ||
* The specification and pictures are subject to change without notice.
* All trademarks and logos are the properties of their respective holders.
