| Computer Connections |
Direct | 16 | |
| Maximum | 256 (via daisy chain) | ||
| Port Selection | OSD; Hotkey; Pushbutton | ||
| Connectors | Console Port | Keyboard | 1 x 6-pin Mini-DIN Female (Purple) 1 x USB Type A Female (White) |
| Video | 1 x HDB-15 Female (Blue) | ||
| Mouse | 1 x 6-pin Mini-DIN Female (Green) 1 x USB Type A Female (White) |
||
| KVM Port | 16 x RJ-45 Female | ||
| Daisy Chain Ports | 1 x DB-25 Male (Black) | ||
| Power | 1 x 3-prong AC socket | ||
| LAN | 1 x RJ-45 Female | ||
| F/W Upgrade | 1 x RJ-11 Female (Black) | ||
| PON | 1 X RJ-45 Female | ||
| Laptop USB Console (LUC) Port |
1 x USB Mini Type B Female (Black) | ||
| Switches | Reset | 1 x Semi-recessed Pushbutton | |
| Power | 1 x Rocker | ||
| Port Selection | 16 x Pushbutton | ||
| LEDs | On Line | 16 (Green) | |
| Selected | 16 (Orange) | ||
| Power | 1 (Blue) | ||
| Station ID | 1 x 2-digit 7-segment (Orange) | ||
| Link | 1 (Orange) | ||
| 10 / 100Mbps | 1 (Orange / Green) | ||
| Emulation | Keyboard / Mouse | PS/2; USB | |
| Video | Local | 1600 x 1200 @ 60 Hz (40m) ; 1280 x 1024 @ 75 Hz (50 m with KA7xx Adapter Cable) |
|
| Remote | 1600 x 1200 @ 60Hz | ||
| Scan Interval | 1–255 secs | ||
| I/P Rating | 100–240 VAC; 50/60 Hz; 1A | ||
| Power Consumption | 120V/12.5W; 230V/12.7W | ||
| Environment | Operating Temp. | 0 - 40°C | |
| Storage Temp. | -20 - 60°C | ||
| Humidity | 0–80% RH; Non-condensing | ||
| Physical Properties |
Housing | Metal | |
| Weight | 2.80 kg | ||
| Dimensions (L x W x H) |
43.70 x 16.10 x 4.40 cm (19"/1U) | ||
